V-100 Custom Mini V Cone Food Milk Coffee Powder Mixer Small V Shape Blending V Type Protein Powder Mixing Machine Food Grade
V-100 V Type Vertical Powder Mixer Machine
Mixer V100 is a mixing machine from CapsulCN. It is suitable for mixing various dry powder and granular materials in chemical and food industries. The mixer has characteristics of simple structure, easy operation and pretty appearance. Its parts in contact with materials are made of stainless steel, which conforms to the CGMP.
Description
V-100 V Type Vertical Powder Mixer Machine
Mixer V100 is a mixing machine from CapsulCN. It is suitable for mixing various dry powder and granular materials in chemical and food industries. The mixer has characteristics of simple structure, easy operation and pretty appearance. Its parts in contact with materials are made of stainless steel, which conforms to the CGMP.
V Type Protein Powder Mixing Machine Technical parameters | |||||||||
Model and specification | V-0.18 | V-0.3 | V-0.5 | V-1.0 | V-1.5 | V-2.0 | V-2.5 | V-3.0 | V-4.0 |
Productive capacity (kg/time) | 72 | 90 | 150 | 300 | 450 | 600 | 800 | 900 | 1200 |
Model of vacuum pump | W2 | W2 | W2 | W3 | W3 | W3 | W3 | W4 | W4 |
Time of raw material fed in (min) | 3-5 | 3-5 | 4-6 | 6-9 | 6-10 | 8-13 | 8-15 | 8-12 | 10-15 |
Mixing time (min) | 4-8 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 8-12 | 8-12 |
Total volume (m³） | 0.18 | 0.3 | 0.5 | 1.0 | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 |
Stirring speed(r/min) | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 10 | 10 |
Power of motor (kw) | 1.1 | 1.1 | 1.5 | 3 | 4 | 5.5 | 7.5 | 7.5 | 11 |
Rotating height (mm) | 1580 | 2160 | 2360 | 2600 | 2800 | 2900 | 3000 | 3200 | 4000 |
Weight (kg) | 280 | 320 | 550 | 950 | 1020 | 1600 | 2040 | 2300 | 2800 |
Notes:all loading coeficient is 0.4-0.6.the productive capacity listed in the table is calculated in accordance with 0.5 of loading coeficient and 0.8 of raw material density. |
V Type Protein Powder Mixing Machine Service before sell:
V Type Protein Powder Mixing Machine Service in sell:
V Type Protein Powder Mixing Machine Service after sell:
1.Can I use this machine to extract some raw materials?
Additional information
| Model Number | V-0.18, V-0.3, V-0.5, V-1.0, V-1.5, V-2.0, V-2.5, V-3.0, V-4.0, V-5.0, V-6.0 |
|---|---|
| Type | Rotary Drying Equipment |
| Application | Chemicals Processing, Plastics Processing, Food Processing, Powder |
| Condition | New |
| Place of Origin | Jiangsu, China |
| Brand Name | CSTECH |
| Voltage | 110V-450V |
| Power | 1.1-18.5kW |
| Dimension(L*W*H) | Depends on the model |
| Key Selling Points | Easy to Operate |
| Warranty | 2 years |
| Weight (KG) | 5000 |
| Applicable Industries | Manufacturing Plant, Food & Beverage Factory, Food Shop, Food & Beverage Shops, Other |
| Showroom Location | None |
| Marketing Type | Hot Product 2023 |
| Machinery Test Report | Provided |
| Video outgoing-inspection | Provided |
| Warranty of core components | 2 years |
| Core Components | Bearing, Pump, Motor, Gearbox, PLC, Engine, Gear |
| Evaporation Capacity(kg/h) | 60 |
| Heating Method | Electric Heating |
| Material | SUS304, SUS304L, SUS316, SUS316L, Ti, Other, SUS304, SUS304L, SUS316, SUS316L, Ti |
| Product name | V Type Blender Mixers |
| Advantage | Low Consumption High Efficiency |
| Max loading volume | 50-2500L |
| Max. Loading Capacity | 6000L |
| Range of Spindle Speed(r.p.m) | 12 – 24 r.p.m |
| Designed pressure in the tank: | -0.1-0.15 Mpa |
| Working temperature | In the tank≤85℃ jacket≤140℃ |
| Certification | ISO9001 |
